$849.99

Manufacturer's Suggested Retail Price excludes shipping costs, assembly, and taxes.

Color — Jet Black

Black

Yellow

Size

24"

Style

Step-Thru

The Atlas Transit is our medium duty trike perfect for hauling groceries from the local market or transporting packages around a warehouse. The frame is designed with the same Low-Step as our Traditional trike making for easy on and off access. Along with a complement of durable components, the 24" version is customizable with 3 different wheel styles. The 20" SD version comes stock with alloy wheels, includes a Sun custom trike saddle with adjustable backrest, and Velcro toe straps for secure foot placement.

Wheels sold separately
High-tensile steel Low-Step frame
Single-speed drivetrain (Additional gearing options available separately)
Alloy linear-pull front brake with parking lock (Additional brake options available separately)
One-piece steel crank with sealed bottom bracket
24" x 1.95" multi-condition tires
13" high-rise steel handlebar and threadless MX stem, rubber grips
Sun XL trike saddle with heavy duty steel base
Steel chain guard and front fender
Viny coated heavy duty steel wire basket
Wheel options:
Skyway mags
Alloy rims with 14g stainless steel spokes
Heavy duty steel rims with 12g UCP steel spokes
MSRP shown includes Skyway mags

Loading store locator from Stockist store locator...

[{"id":45340849242301,"title":"Black \/ 24\" \/ Step-Thru","option1":"Black","option2":"24\"","option3":"Step-Thru","sku":"670205","requires_shipping":true,"taxable":true,"featured_image":{"id":38233740312765,"product_id":8069018714301,"position":1,"created_at":"2025-09-03T10:46:00-07:00","updated_at":"2025-09-03T10:46:03-07:00","alt":"670205","width":2200,"height":1500,"src":"\/\/sun.bike\/cdn\/shop\/files\/670205_2306dfca-c902-4837-b750-d86e816976ac.jpg?v=1756921563","variant_ids":[45340849242301]},"available":false,"name":"Atlas Transit - Black \/ 24\" \/ Step-Thru","public_title":"Black \/ 24\" \/ Step-Thru","options":["Black","24\"","Step-Thru"],"price":84999,"weight":24494,"compare_at_price":null,"inventory_management":"shopify","barcode":"888571014585","featured_media":{"alt":"670205","id":29506413002941,"position":1,"preview_image":{"aspect_ratio":1.467,"height":1500,"width":2200,"src":"\/\/sun.bike\/cdn\/shop\/files\/670205_2306dfca-c902-4837-b750-d86e816976ac.jpg?v=1756921563"}},"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":45340849275069,"title":"Yellow \/ 24\" \/ Step-Thru","option1":"Yellow","option2":"24\"","option3":"Step-Thru","sku":"670206","requires_shipping":true,"taxable":true,"featured_image":{"id":38233740345533,"product_id":8069018714301,"position":2,"created_at":"2025-09-03T10:46:00-07:00","updated_at":"2025-09-03T10:46:03-07:00","alt":"670206","width":2200,"height":1500,"src":"\/\/sun.bike\/cdn\/shop\/files\/670206_f7f4df17-9525-438c-b261-4aa0e098716d.jpg?v=1756921563","variant_ids":[45340849275069]},"available":false,"name":"Atlas Transit - Yellow \/ 24\" \/ Step-Thru","public_title":"Yellow \/ 24\" \/ Step-Thru","options":["Yellow","24\"","Step-Thru"],"price":84999,"weight":24675,"compare_at_price":null,"inventory_management":"shopify","barcode":"888571014592","featured_media":{"alt":"670206","id":29506413035709,"position":2,"preview_image":{"aspect_ratio":1.467,"height":1500,"width":2200,"src":"\/\/sun.bike\/cdn\/shop\/files\/670206_f7f4df17-9525-438c-b261-4aa0e098716d.jpg?v=1756921563"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

{"id":45340849242301,"title":"Black \/ 24\" \/ Step-Thru","option1":"Black","option2":"24\"","option3":"Step-Thru","sku":"670205","requires_shipping":true,"taxable":true,"featured_image":{"id":38233740312765,"product_id":8069018714301,"position":1,"created_at":"2025-09-03T10:46:00-07:00","updated_at":"2025-09-03T10:46:03-07:00","alt":"670205","width":2200,"height":1500,"src":"\/\/sun.bike\/cdn\/shop\/files\/670205_2306dfca-c902-4837-b750-d86e816976ac.jpg?v=1756921563","variant_ids":[45340849242301]},"available":false,"name":"Atlas Transit - Black \/ 24\" \/ Step-Thru","public_title":"Black \/ 24\" \/ Step-Thru","options":["Black","24\"","Step-Thru"],"price":84999,"weight":24494,"compare_at_price":null,"inventory_management":"shopify","barcode":"888571014585","featured_media":{"alt":"670205","id":29506413002941,"position":1,"preview_image":{"aspect_ratio":1.467,"height":1500,"width":2200,"src":"\/\/sun.bike\/cdn\/shop\/files\/670205_2306dfca-c902-4837-b750-d86e816976ac.jpg?v=1756921563"}},"requires_selling_plan":false,"selling_plan_allocations":[]}

Details

Product Specifications

Name: Atlas Transit
Brand: SUN BICYCLES
SKU: 670205
Price: 849.99 USD
Availability: OutOfStock

Frameset

Frame

High-Tensile Steel, TIG-Welded

Frame Rear Unit

High Tensile Steel, TIG-Welded, Disc and Der Compatible

Fork

1-1/8" Hi Tensile Steel, Curved Legs, Double Eyelets

Drivetrain

Crank Set

One-Piece Heavy Duty Hot Forged Steel, 170mm

Chainwheel

Steel, 36T x 1/2'' x 1/8''

Bottom Bracket

Steel for OPC, Caged Bearings with Seal

Freewheel

20T x 1/2" x 1/8"

Chain

Taya 1/2" x 1/8", 130 Links

Pedals

Slip Resistant Top, 1/2"

Brakes

Front Brake

Alloy, Linear Pull

Front Brake Lever

Alloy, Linear Pull w/ 3-Finger Lever and Parking Lock

Components

Handlebar

Steel, 31.5" Wide 13" Rise x 22.2mm Clamp

Stem

Alloy, Threadless, 28.6 x 50mm x 0 deg x 22mm Clamp

Headset

Steel, Semi Cartridge Bearings, 28.6 x 34 x 30mm

Grips

Heavy Duty Rubber, 125mm

Saddle

Deluxe Cruiser, Double Coil Spring Suspension

Seat Post

Steel w/o Clamp, W/Anti-Slip Knurling, 28.6 x 12"

Seat Clamp / Binder Bolt

Integrated Bolt/Nut Type

Wheels

Front Wheel

Ordered Separately

Rear Wheel

Ordered Separately

Tires

24 x 1.95", Black Wall

Tubes

24" x 1.95'', Schrader Valve

Included Extras

Chain Guard

Steel, Painted

Basket

Heavy Duty Steel, Black Vinyl Coated, 21" Long x 15" Wide x 9" High

Front Fender

Steel, W/Single Strut, Painted

Weight

Trike Weight

56 Lbs (with Skyway mags)

Rider Weight Limit

250 Lbs.

Basket Weight Limit

50 Lbs. (Not Designed for People or Pets)

Recommended Fit

5'0" to 6'2"

Notes

Pricing & Specifications

We reserve the right to modify this product’s specifications, colors, and materials without prior notice. Additionally, retail prices may vary from the Manufacturer's Suggested Retail Price (MSRP), which does not include shipping, assembly, or taxes.

Bike Geometry

Measurement	Ref	17"
Seat Tube, Center To Top	A	17"
Top Tube, Effective	B	27.5"
Top Tube, Actual	B4	26"
Head Tube	C	5.5"
Seat Tube Angle	D	70°
Head Tube Angle	E	70°
Chainstay	F	23"
Wheelbase	G	46.3"
Bottom Bracket Drop	H	1.9"
Fork Offset	I	1.8"
Axle To Crown	K	14.5"
Step-Thru / Standover	N	13.25"
Minimum Step Through	O	13.25"
Minimum Saddle To Ground		27.5"
Minimum Saddle To Pedal, Trike		27.5"
Overall Length, Trike	U	71.5"
Overall Height, Trike	W	45"
Overall Width, Trike	V	30.25"
Wheel Size		24"
Crank Length		170mm
Stem Length		50mm
Handlebar Width		31.5" Wide / 13" Rise
