Details
Product Specifications
Frameset
Frame
6061 Series Alumimum, TIG-Welded, Foot Forward Design
Fork
1-1/8" High Tensile Steel, Straight Legs
Drivetrain
Crankset
3-Piece Alloy W/Integrated Chainring, 170mm
Chainring
Steel, 42T x 1/2'' x 1/8'', Painted
Bottom Bracket
Sealed Cartridge
Sprocket
20T x 1/2" x 1/8"
Chain
K.M.C. 1/2" x 1/8"
Rear Shifter
Shimano 3-Speed Revo Twist Shifter
Pedals
Slip Resistant Top, 9/16", Black
Brakes
Front Brake
Alloy, Linear Pull
Rear Brake
Shimano Nexus Inter-3 Coaster Brake
Brake Lever
Alloy, 4-Finger Lever
Components
Handlebar
Alloy, 26.3'' Wide x 6'' Rise x 25.4mm Clamp
Stem
Alloy, 25.4 x 180mm Quill x 85mm Ext. x 25.4 Clamp
Headset
Semi Integrated, Steel with Caged Bearings, 25.4 x 44 x 30mm
Grips
Kraton Rubber Ergonomic, L-135mm/R-92mm, Black
Saddle
Sport Cruiser, Elastomer Suspension
Seat Post
Alloy w/o Clamp, 27.2 X 350mm
Seat Clamp
Alloy, 31.8mm I.D., with Q/R
Wheels
Front Wheel
26" x 1.75 x 36H x 14G Alloy-Cruiser, Bolt-On
Rear Wheel
26" x 1.75 x 36H x 14G Alloy-Cruiser, W/Nexus-3 Coaster Brake
Front Hub
Alloy, 36H x 14G x 3/8" Bolt-On Axle
Rear Hub
Shimano Nexus Inter-3 Coaster Brake, 36H x 14G
Spokes
14G Stainless Steel with CP Brass Nipples (F-265 / R-259 / N- )
Rims
26" x 36H x 14G, Alloy
Tires
26" x 2.25", Black Wall
Tubes
26" x 2.25", Schrader Valve
Included Extras
Fender Front
Steel, Single Strut, Painted
Fender Rear
Steel, Single Strut, Painted
Kickstand
Alloy, Center Mount
Weight
Bike Weight
31 Lbs.
Rider Weight Limit
250 Lbs.
Notes
Pricing & Specifications
We reserve the right to modify this product’s specifications, colors, and materials without prior notice. Additionally, retail prices may vary from the Manufacturer's Suggested Retail Price (MSRP), which does not include shipping, assembly, or taxes.
Bike Geometry
| Measurement | Ref | 17.5" | 19" |
|---|---|---|---|
| Seat Tube, Center To Top | A | 17.5" | 19" |
| Top Tube, Effective | B | 24.9" | 26.2" |
| Top Tube, Actual | B4 | 22.1" | 23.2 |
| Head Tube | C | 8.3" | 9.4" |
| Seat Tube Angle | D | 61.5 | 61.5 |
| Head Tube Angle | E | 68 | 68 |
| Chainstay | F | 21.6" | 21.6" |
| Wheelbase | G | 45.1" | 46.1" |
| Bottom Bracket Drop | H | 2.4" | 2.4" |
| Fork Offset | I | 2.4" | 2.4" |
| Trail | J | 62mm | 62mm |
| Axle To Crown | K | 14.6" | 14.6" |
| Step-Thru / Standover | N | 18.3" | 32" |
| Minimum Step Through | O | 18.3" | 32" |
| Minimum Saddle To Ground | 30.5" | 32.5" | |
| Minimum Saddle To Pedal | 28" | 30" | |
| Maximum Saddle To Pedal | 35.5" | ||
| Suggested Rider Inseam | 34" | ||
| Wheel Size | 26" | 26" | |
| Crank Length | 170 mm | 170 mm | |
| Stem Length | 80 mm | 80 mm | |
| Handlebar Width | 26.5" Wide / 6.3" Rise | 26.5" Wide / 6.3" Rise |
