Details
Product Specifications
Frameset
Frame
High-Tensile Steel, TIG-Welded
Fork
1-1/8" Hi Tensile Steel, Curved Legs, Single Eyelets
Drivetrain
Crankset
3-Piece Alloy, 170x28/38/48
Chainring
Steel, 28/38/48T
Bottom Bracket
Sealed Cartridge, 68 x 119mm
Freewheel
Shimano (7-Speed) 14-34T
Chain
K.M.C. 1/2 x 3/32''
Front Derailleur
Shimano Tourney
Rear Derailleur
Shimano Tourney
Front Shifter
Shimano Tourney 3-Speed Twist Shifter
Rear Shifter
Shimano Tourney 7-Speed Twist Shifter
Pedals
Slip-Resistant Top, 9/16"
Brakes
Front Brake
Alloy, Linear Pull
Rear Brake
Alloy, Linear Pull
Brake Lever
Alloy, 4-Finger Lever
Components
Handlebar
Steel, 640mm Wide x 80mm Rise x 25.4mm Clamp
Stem
Alloy, 25.4 x 180mm Quill x 80mm Ext. x 30 Deg. Rise x 25.4mm Clamp
Headset
Steel, Caged Bearings, 25.4 x 34 x 30mm
Grips
Kraton Rubber, 92mm Left / 92mm Right
Saddle
Sport Cruiser, Elastomer Suspension
Seat Post
Alloy W/Integrated Clamp, 25.4 x 350mm
Seat Clamp
Alloy, 28.6mm I.D., with Q/R Lever
Wheels
Front Wheel
700C x 36H x 14G, Alloy-Commuter, Q/R
Rear Wheel
700C x 36H x 14G, Alloy-Commuter, Q/R, (For Freewheel)
Front Hub
Alloy, 36H x 14G with Q/R Axle
Rear Hub
Alloy, 36H x 14G with Q/R Axle, (For Freewheel)
Spokes
14G Stainless Steel with Brass Nipples (F-294 / D-291 - ND-293 / N-12mm)
Rims
700c x 36H x 14G, Alloy, CNC
Tires
700 x 38mm, Black Wall
Included Extras
Kickstand
Alloy, Center Mount
Weight
Bike Weight
32 Lbs.
Rider Weight Limit
250 Lbs.
Notes
Pricing & Specifications
We reserve the right to modify this product’s specifications, colors, and materials without prior notice. Additionally, retail prices may vary from the Manufacturer's Suggested Retail Price (MSRP), which does not include shipping, assembly, or taxes.
Bike Geometry
| Measurement | Ref | 15.5" Step-Thru | 16.5" Step-Over | 17.5" Step-Thru | 19" Step-Thru | 20.5" Step-Over |
|---|---|---|---|---|---|---|
| Seat Tube, Center To Top | A | 15.5" | 16.5" | 17.5" | 19" | 20.5" |
| Top Tube, Effective | B | 22.4" | 22.6" | 23" | 23.6" | 23.6" |
| Top Tube, Actual | B4 | 21.4" | 21.5" | 21.8" | 22.2" | 22.5" |
| Head Tube | C | 6.1" | 5.5" | 6.9" | 7.7" | 7.1" |
| Seat Tube Angle | D | 71.5° | 71.5° | 71.5° | 71.5° | 71.5° |
| Head Tube Angle | E | 70.5° | 70.5° | 70.5° | 70.5° | 70.5° |
| Chainstay | F | 17.9 | 17.9" | 17.9" | 17.9 | 17.9" |
| Wheelbase | G | 41.8" | 41.9" | 42.3" | 43.3" | 42.5" |
| Bottom Bracket Drop | H | 2.6" | 2.6" | 2.6" | 2.6" | 2.6" |
| Bottom Bracket To Ground | H1 | 11" | 11" | 11" | 11" | 11" |
| Fork Offset | I | 1.9" | 1.9" | 1.9" | 1.9" | 1.9" |
| Trail | J | 3" | 3" | 3" | 3" | 3" |
| Axle To Crown | K | 16.2" | 16.2" | 16.2" | 16.2" | 16.2' |
| Stack | L | 23.3" | 22.7" | 24" | 24.8" | 24.2" |
| Reach | M | 14.6" | 15" | 15" | 15.3" | 15.5" |
| Step-Thru / Standover | N | 18" | 25.5" | 18" | 18" | 29.25" |
| Minimum Step Through | O | 18" | 18" | 18" | ||
| Minimum Saddle To Ground | 32.5" | |||||
| Minimum Saddle To Pedal | 26" | 27" | 28" | 29.5" | 31" | |
| Suggested Rider Inseam | 27.5" | 33" | ||||
| Wheel Size | 700c | 700c | 700c | 700c | 700c | |
| Crank Length | 170mm | 170mm | 170mm | 170mm | 170mm | |
| Stem Length | 80mm | 80mm | 80mm | 80mm | 80mm | |
| Handlebar Width | 25" Wide / 3" Rise | 25" Wide / 3" Rise | 25" Wide / 3" Rise | 25" Wide / 3" Rise | 25" Wide / 3" Rise |
