Details
Product Specifications
Frameset
Frame
High-Tensile Steel, TIG-Welded
Fork
1-1/8" High-Tensile Steel, Curved Legs, Double Eyelets
Drivetrain
Crankset
One-Piece Steel, 170mm
Chainring
Steel, 42T x 1/2" x 1/8"
Bottom Bracket
Steel for OPC, Caged Bearings
Sprocket
19T x 1/2" x 1/8"
Chain
K.M.C., 1/2" x 1/8"
Pedals
Slip Resistant Top, 1/2"
Brakes
Rear Brake
KT Coaster Brake
Components
Handlebar
Steel, 700mm Wide x 113mm Rise x 25.4mm Clamp
Stem
Alloy, 25.4 x 180mm Quill x 80mm Ext. x 30 Deg. Rise x 25.4mm Clamp
Headset
Steel, Caged Bearings, 25.4 x 34 x 30mm
Grips
Foam, Black
Saddle
Cruiser, Coil Spring Suspension
Seat Post
Steel w/o Clamp, 25.4 x 350mm
Seat Clamp
Alloy, 28.6mm I.D., with Bolt
Wheels
Front Hub
Steel, 36H x 14G with 3/8" Bolt-On Axle
Rear Hub
KT Coaster Brake, 36H x 14G
Spokes
14G Stainless Steel with CP Brass Nipples
Rims
26" x 36H x 14G, Alloy
Tires
26" x 2.25", Black Wall
Tubes
26" x 1.90-2.35", Schrader Valve
Included Extras
Chainguard
Steel, Painted
Kickstand
Alloy, Center Mount
Weight
Bike Weight
33 Lbs.
Rider Weight Limit
250 Lbs.
Notes
Pricing & Specifications
We reserve the right to modify this product’s specifications, colors, and materials without prior notice. Additionally, retail prices may vary from the Manufacturer's Suggested Retail Price (MSRP), which does not include shipping, assembly, or taxes.
Bike Geometry
| Measurement | Ref | 16" Step-Thru | 18.5" Step-Over |
|---|---|---|---|
| Seat Tube, Center To Top | A | 16" | 18.5" |
| Top Tube, Effective | B | 25.90" | 26.95" |
| Head Tube | C | 5.3" | 6.69" |
| Seat Tube Angle | D | 67° | 67° |
| Head Tube Angle | E | 69° | 69° |
| Chainstay | F | 19.4" | 19.41" |
| Wheelbase | G | 45.93" | 46.92" |
| Bottom Bracket Drop | H | 2.36" | 2.36" |
| Fork Offset | I | 2.36" | 2.36" |
| Axle To Crown | K | 14.56" | 14.4" |
| Step-Thru / Standover | N | 17.3" | 29.5" |
| Minimum Saddle To Ground | 30" | 33" | |
| Minimum Saddle To Pedal | 27.25" | 30" | |
| Suggested Rider Height | 5'0' - 5'8" | 5'4" - 6'2' | |
| Suggested Rider Inseam | 25" - 32" | 27.5" - 34.5" | |
| Wheel Size | 26" | 26" | |
| Crank Length | 170 mm | 170 mm | |
| Stem Length | 90 mm | 90 mm | |
| Handlebar Width | 27.5" Wide / 8.4" Rise | 27.5" Wide / 8.4" Rise |
