$449.99

Manufacturer's Suggested Retail Price excludes shipping costs, assembly, and taxes.

Color — Mint Pearl

Green

Size

16"

Style

Step-Thru

Classic high-tensile steel frame
Single-speed coaster brake version also available in a 24" wheel for smaller riders - limited colors
One-piece steel crank
Alloy rims with stainless steel spokes
26" x 2.50" cruiser tires
Mid-rise steel cruiser handlebar
Sun Cruiser saddle
Steel chain guard
Steel kickstand

Loading store locator from Stockist store locator...

[{"id":45340850159805,"title":"Green \/ 16\" \/ Step-Thru","option1":"Green","option2":"16\"","option3":"Step-Thru","sku":"670538","requires_shipping":true,"taxable":true,"featured_image":{"id":41997369901245,"product_id":8069019336893,"position":1,"created_at":"2026-09-22T02:18:26-07:00","updated_at":"2026-09-22T02:18:29-07:00","alt":"670538","width":2200,"height":1500,"src":"\/\/sun.bike\/cdn\/shop\/files\/670538_462a6688-291c-4a34-b0fc-e8c8aee8f538.jpg?v=1790068709","variant_ids":[45340850159805]},"available":false,"name":"Revolutions CB-26 - Green \/ 16\" \/ Step-Thru","public_title":"Green \/ 16\" \/ Step-Thru","options":["Green","16\"","Step-Thru"],"price":44999,"weight":19867,"compare_at_price":null,"inventory_management":"shopify","barcode":"888571038215","featured_media":{"alt":"670538","id":41547145773245,"position":1,"preview_image":{"aspect_ratio":1.467,"height":1500,"width":2200,"src":"\/\/sun.bike\/cdn\/shop\/files\/670538_462a6688-291c-4a34-b0fc-e8c8aee8f538.jpg?v=1790068709"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

{"id":45340850159805,"title":"Green \/ 16\" \/ Step-Thru","option1":"Green","option2":"16\"","option3":"Step-Thru","sku":"670538","requires_shipping":true,"taxable":true,"featured_image":{"id":41997369901245,"product_id":8069019336893,"position":1,"created_at":"2026-09-22T02:18:26-07:00","updated_at":"2026-09-22T02:18:29-07:00","alt":"670538","width":2200,"height":1500,"src":"\/\/sun.bike\/cdn\/shop\/files\/670538_462a6688-291c-4a34-b0fc-e8c8aee8f538.jpg?v=1790068709","variant_ids":[45340850159805]},"available":false,"name":"Revolutions CB-26 - Green \/ 16\" \/ Step-Thru","public_title":"Green \/ 16\" \/ Step-Thru","options":["Green","16\"","Step-Thru"],"price":44999,"weight":19867,"compare_at_price":null,"inventory_management":"shopify","barcode":"888571038215","featured_media":{"alt":"670538","id":41547145773245,"position":1,"preview_image":{"aspect_ratio":1.467,"height":1500,"width":2200,"src":"\/\/sun.bike\/cdn\/shop\/files\/670538_462a6688-291c-4a34-b0fc-e8c8aee8f538.jpg?v=1790068709"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}

Details

Product Specifications

Name: Revolutions CB-26
Brand: Sun Bicycles
SKU: 670538
Price: 449.99 USD
Availability: OutOfStock

Frameset

Frame

High-Tensile Steel, TIG-Welded

Fork

1'' High Tensile Steel, Curved Legs, Double Eyelets

Drivetrain

Crankset

One-Piece Steel, 6-1/2''

Chainring

Steel, 42T x 1/2'' x 1/8''

Bottom Bracket

Steel for OPC, Caged Bearings

Sprocket

22T x 1/2" x 1/8"

Chain

K.M.C. 1/2" x 1/8"

Pedals

Slip Resistant Top, 1/2"

Brakes

Rear Brake

KT Internal Coaster Brake

Components

Handlebar

Steel, 680mm Wide x 85mm Rise x 25.4mm Clamp

Stem

Alloy, 22.2 x 180mm Quill x 80mm Ext. x 25.4mm Clamp, 30° Rise

Headset

Steel, Caged Bearings, 22.2 x 30 x 27mm

Grips

Foam, Black

Saddle

Comfort Cruiser, Elastomer Suspension

Seat Post

Steel w/o Clamp, 25.4 x 350mm

Seat Clamp

Alloy, 28.6mm I.D., with Bolt

Wheels

Front Hub

Steel, 36H x 14G with 3/8" Bolt-On Axle

Rear Hub

Coaster Brake, 36H x 14G

Spokes

14G Stainless Steel with Brass Nipples (F-264 / R-260 / N-12mm)

Rims

26" x 36H x 14G, Alloy

Tires

Cruiser, Sand Storm 26 x 2.50"

Tubes

26" x 2.35-2.75'', Schrader Valve

Included Extras

Kickstand

Steel, Center Mount

Weight

Bike Weight

33 Lbs.

Rider Weight Limit

250 Lbs.

Notes

Pricing & Specifications

We reserve the right to modify this product’s specifications, colors, and materials without prior notice. Additionally, retail prices may vary from the Manufacturer's Suggested Retail Price (MSRP), which does not include shipping, assembly, or taxes.

Bike Geometry

Measurement	Ref	16" Step-Thru	18.5" Step-Over
Frame Size	A	16" Step-Thru	18.5" Step-Over
Seat Tube, Center To Top	A	16"	18.5"
Top Tube, Effective	B	25.9"	27"
Head Tube	C	5.3"	6.7"
Seat Tube Angle	D	67°	67°
Head Tube Angle	E	69°	69°
Chainstay	F	19.4"	19.4"
Wheelbase	G	45.9"	46.9"
Bottom Bracket Drop	H	2.4"	2.4"
Fork Offset	I	2.4"	2.4"
Axle To Crown	K	14.6"	14.6"
Step-Thru / Standover	N	18.5"	31.5"
Minimum Saddle To Ground		30.5"	33"
Minimum Saddle To Pedal		27"	29.5"
Maximum Saddle To Pedal		35"	37"
Suggested Rider Height		5'0' - 5'8"	5'4" - 6'2"
Suggested Rider Inseam		25" - 32"	27.5" - 34.5"
Wheel Size		26"	26"
Crank Length		170 mm	170 mm
Stem Length		80 mm	80 mm
Handlebar Width		27.5" Wide / 8.4" Rise	27.5" Wide / 8.4" Rise

Revolutions CB-26
